Case No. 9  Materials

Marbles at f/1.8

Shallow depth of field from cam.data.dof: one marble sharp, the rest falling off into blur.

● Materials · CyclesRTX PRO 6000 · Tokyo
Marbles with shallow depth of field (f/1.8)
Cycles1920 × 1080Samples 128PNG still
Fig. — Marbles with shallow depth of field (f/1.8). A real render from the production GPU.
The short answer

This macro still of marbles on a wooden table was rendered on a JANCTION GPU with shallow depth of field at f/1.8. cam.data.dof.focus_object picks the sharp marble and aperture_fstop sets how quickly the others blur. It took 7.3 GPU seconds on the production GPU, 0.7 JPY at 0.1 JPY per GPU-second.

What is in the frame

Glossy pastel marbles and a few chrome ones on a table, with one in focus and the rest dissolving into soft blur. Depth of field is what makes a small object feel close to the lens.

How the scene is built

The camera's depth of field is enabled in the script. focus_object locks focus on one marble, and an aperture of f/1.8 gives a narrow sharp zone. Cycles renders the blur physically, so it needs enough samples to stay clean; denoising is on by default.

Adapt it

Raise the f-number for more of the scene in focus, or point focus_object at a different marble. Preview at 720p to judge the blur before the 1080p final.

0.7 JPY for this render. The free welcome credit of a new key covers about 137 of them, with no card.

Render this example with your AI

ChatGPT · Claude · Grok · Perplexity

Use JANCTION Render (MCP server https://render.janction.jp/mcp) to render this example: render_preview(scene_url="https://render.janction.jp/samples/ex09_macro_marbles.py"). Then suggest how to change the colors, shapes and camera for my own subject. Ask me before the final render.

Each link opens the app with the text below filled in (if it is not, copy and paste it). If JANCTION Render is not connected in that app yet, add https://render.janction.jp/mcp as a connector first.

Blender warnings

  • environment preset 'studio' replaced the scene's world (HDRI lighting)

The script (bpy, runs as is)

ex09_macro_marbles.py. It builds the scene, the camera and the frame range; resolution, samples, denoising and the GPU are set by the service.

"""JANCTION Render example 09: marbles on a wooden table, shallow depth of field at f/1.8 (one still).

Reproduce: render_final(scene_url="https://render.janction.jp/samples/ex09_macro_marbles.py",
                        width=1920, height=1080, samples=128, environment="studio")
Depth of field is cam.data.dof: focus_object picks the sharp marble, aperture_fstop sets the blur.
"""
import random

import bpy
from mathutils import Vector

for ob in list(bpy.data.objects):
    bpy.data.objects.remove(ob, do_unlink=True)
scene = bpy.context.scene
scene.frame_start = 1
scene.frame_end = 1


def material(name, color, roughness=0.5, metallic=0.0, **inputs):
    mat = bpy.data.materials.new(name)
    mat.use_nodes = True
    bsdf = mat.node_tree.nodes["Principled BSDF"]
    bsdf.inputs["Base Color"].default_value = (*color, 1.0)
    bsdf.inputs["Roughness"].default_value = roughness
    bsdf.inputs["Metallic"].default_value = metallic
    for key, value in inputs.items():
        bsdf.inputs[key].default_value = value
    return mat


def smooth(ob):
    for p in ob.data.polygons:
        p.use_smooth = True
    return ob


def add(op, name, mat=None, **kw):
    getattr(bpy.ops.mesh, op)(**kw)
    ob = bpy.context.object
    ob.name = name
    if mat is not None:
        ob.data.materials.append(mat)
    return ob


def look_at(ob, target):
    ob.rotation_euler = (Vector(target) - ob.location).to_track_quat("-Z", "Y").to_euler()


def light(name, kind, location, energy, target=None, size=1.0, color=(1.0, 1.0, 1.0)):
    data = bpy.data.lights.new(name, kind)
    data.energy = energy
    data.color = color
    if kind == "AREA":
        data.size = size
    ob = bpy.data.objects.new(name, data)
    scene.collection.objects.link(ob)
    ob.location = location
    if target is not None:
        look_at(ob, target)
    return ob


table = material("Table", (0.45, 0.28, 0.16), roughness=0.35)
add("primitive_plane_add", "Table", table, size=12)

colors = [(0.9, 0.2, 0.15), (0.2, 0.5, 0.9), (0.95, 0.75, 0.2), (0.3, 0.75, 0.35), (0.85, 0.85, 0.9),
          (0.6, 0.25, 0.7), (0.95, 0.5, 0.2), (0.2, 0.7, 0.7), (0.95, 0.95, 0.95)]
rng = random.Random(3)
focus = None
for i, color in enumerate(colors):
    gx, gy = i % 3, i // 3
    x = (gx - 1) * 0.72 + rng.uniform(-0.12, 0.12)
    y = (gy - 1) * 0.72 + rng.uniform(-0.12, 0.12)
    if i in (4, 8):
        mat = material("Marble%d" % i, color, roughness=0.15, metallic=1.0)
    else:
        mat = material("Marble%d" % i, color, roughness=0.05, **{"Coat Weight": 1.0, "Coat Roughness": 0.02})
    ball = add("primitive_uv_sphere_add", "Marble%d" % i, mat, radius=0.3, segments=96, ring_count=48, location=(x, y, 0.3))
    smooth(ball)
    if i == 4:
        focus = ball

light("Key", "AREA", (1.5, -1.5, 2.0), 150, target=(0, 0, 0.3), size=1.5)

data = bpy.data.cameras.new("Camera")
data.lens = 60
data.dof.use_dof = True
data.dof.focus_object = focus
data.dof.aperture_fstop = 1.8
cam = bpy.data.objects.new("Camera", data)
scene.collection.objects.link(cam)
cam.location = (0.5, -3.1, 1.35)
look_at(cam, (0.0, 0.0, 0.3))
scene.camera = cam

Questions about this case

How do I add depth of field to a Blender camera with Python?

Set cam.data.dof.use_dof = True, choose focus_object or focus_distance, and set aperture_fstop. Lower f-numbers give a shallower focus.

Is denoising on by default?

Yes. Pass denoise=false to turn it off.
