Case No. 20  Product shot

Two product boxes with printed panels

Bevelled cubes, a thin coloured slab for the print and extruded text just in front of the face.

● Product shot · CyclesRTX PRO 6000 · Tokyo
Packaging: two product boxes with printed panels and text
Cycles1920 × 1080Samples 128PNG still
Fig. — Packaging: two product boxes with printed panels and text. A real render from the production GPU.
The short answer

This packaging shot of two cardboard product boxes with printed panels and text was rendered on a JANCTION GPU from a bpy script. The boxes are bevelled cubes; the print is a thin slab plus extruded text, and editing the strings changes the product names. It took 7.0 GPU seconds on the production GPU, 0.7 JPY at 0.1 JPY per GPU-second.

What is in the frame

Two cereal-style boxes with a product name, a short description and a weight on the front panel. Packaging mock-ups are needed long before the first print run.

How the scene is built

Each box is a cube with a bevel modifier for soft edges. The print is not a texture; it is a thin coloured slab and extruded text placed just in front of the face, so no image files are needed.

Adapt it

Edit the strings for your own product names and weights. To use real artwork, send it as an asset and map it onto the face instead of the slab.

0.7 JPY for this render. The free welcome credit of a new key covers about 143 of them, with no card.

Render this example with your AI

ChatGPT · Claude · Grok · Perplexity

Use JANCTION Render (MCP server https://render.janction.jp/mcp) to render this example: render_preview(scene_url="https://render.janction.jp/samples/ex20_packaging_box.py"). Then suggest how to change the colors, shapes and camera for my own subject. Ask me before the final render.

Each link opens the app with the text below filled in (if it is not, copy and paste it). If JANCTION Render is not connected in that app yet, add https://render.janction.jp/mcp as a connector first.

Blender warnings

  • environment preset 'studio' replaced the scene's world (HDRI lighting)

The script (bpy, runs as is)

ex20_packaging_box.py. It builds the scene, the camera and the frame range; resolution, samples, denoising and the GPU are set by the service.

"""JANCTION Render example 20: two cardboard product boxes with printed panels and text (packaging shot, one still).

Reproduce: render_final(scene_url="https://render.janction.jp/samples/ex20_packaging_box.py",
                        width=1920, height=1080, samples=128, environment="studio")
Boxes are bevelled cubes; the print is a thin coloured slab plus extruded text sitting just in front of the face.
Edit the strings to put your own product name on the box.
"""
import math
import random

import bpy
from mathutils import Vector

for ob in list(bpy.data.objects):
    bpy.data.objects.remove(ob, do_unlink=True)
scene = bpy.context.scene
scene.frame_start = 1
scene.frame_end = 1
scene.render.fps = 24
random.seed(20)


def material(name, color, roughness=0.5, metallic=0.0, **inputs):
    mat = bpy.data.materials.new(name)
    mat.use_nodes = True
    bsdf = mat.node_tree.nodes["Principled BSDF"]
    bsdf.inputs["Base Color"].default_value = (*color, 1.0)
    bsdf.inputs["Roughness"].default_value = roughness
    bsdf.inputs["Metallic"].default_value = metallic
    for key, value in inputs.items():
        bsdf.inputs[key].default_value = value
    return mat


def smooth(ob):
    for p in ob.data.polygons:
        p.use_smooth = True
    return ob


def add(op, name, mat=None, **kw):
    getattr(bpy.ops.mesh, op)(**kw)
    ob = bpy.context.object
    ob.name = name
    if mat is not None:
        ob.data.materials.append(mat)
    return ob


def text(body, name, mat, location, size=1.0, extrude=0.02, rotation=(math.pi / 2, 0, 0), align="CENTER"):
    cu = bpy.data.curves.new(name, type="FONT")
    cu.body = body
    cu.size = size
    cu.extrude = extrude
    cu.align_x = align
    ob = bpy.data.objects.new(name, cu)
    scene.collection.objects.link(ob)
    ob.location = location
    ob.rotation_euler = rotation
    ob.data.materials.append(mat)
    return ob


def look_at(ob, target):
    ob.rotation_euler = (Vector(target) - ob.location).to_track_quat("-Z", "Y").to_euler()


def camera(location, target, lens=50.0, name="Camera", active=True, fstop=None, focus=None):
    data = bpy.data.cameras.new(name)
    data.lens = lens
    if fstop is not None:
        data.dof.use_dof = True
        data.dof.aperture_fstop = fstop
        data.dof.focus_distance = focus if focus is not None else (Vector(target) - Vector(location)).length
    cam = bpy.data.objects.new(name, data)
    scene.collection.objects.link(cam)
    cam.location = location
    look_at(cam, target)
    if active:
        scene.camera = cam
    return cam


def light(name, kind, location, energy, target=None, size=1.0, color=(1.0, 1.0, 1.0)):
    data = bpy.data.lights.new(name, kind)
    data.energy = energy
    data.color = color
    if kind == "AREA":
        data.size = size
    ob = bpy.data.objects.new(name, data)
    scene.collection.objects.link(ob)
    ob.location = location
    if target is not None:
        look_at(ob, target)
    return ob


def world(color=(0.02, 0.02, 0.03), strength=1.0):
    w = bpy.data.worlds.new("World")
    w.use_nodes = True
    bg = w.node_tree.nodes["Background"]
    bg.inputs[0].default_value = (*color, 1.0)
    bg.inputs[1].default_value = strength
    scene.world = w
    return w

card = material("Card", (0.93, 0.9, 0.84), roughness=0.75)
floor = material("Floor", (0.86, 0.86, 0.84), roughness=0.35)
wall = material("Wall", (0.92, 0.92, 0.9), roughness=0.8)
ink = material("Ink", (0.08, 0.08, 0.1), roughness=0.5)
add("primitive_plane_add", "Floor", floor, size=24)
back = add("primitive_plane_add", "Backdrop", wall, size=24, location=(0, 4, 6))
back.rotation_euler = (math.pi / 2, 0, 0)


def box(x, w, d, h, color, name, title, sub, yaw=0.0):
    pivot = bpy.data.objects.new(f"Box_{name}", None)
    scene.collection.objects.link(pivot)
    pivot.location = (x, 0, 0)
    pivot.rotation_euler = (0, 0, yaw)
    b = add("primitive_cube_add", f"Body_{name}", card, size=1, location=(0, 0, h / 2))
    b.scale = (w / 2, d / 2, h / 2)
    bev = b.modifiers.new("Bevel", "BEVEL")
    bev.width = 0.012
    bev.segments = 4
    panel = material(f"Print_{name}", color, roughness=0.5)
    p = add("primitive_cube_add", f"Panel_{name}", panel, size=1, location=(0, -d / 2 - 0.004, h * 0.62))
    p.scale = (w / 2 * 0.86, 0.004, h / 2 * 0.5)
    t1 = text(title, f"Title_{name}", ink, (0, -d / 2 - 0.012, h * 0.72), size=w * 0.22, extrude=0.004)
    t2 = text(sub, f"Sub_{name}", ink, (0, -d / 2 - 0.012, h * 0.5), size=w * 0.1, extrude=0.003)
    for ob in (b, p, t1, t2):
        ob.parent = pivot
    return pivot


box(-0.95, 1.4, 0.45, 2.0, (0.95, 0.55, 0.15), "A", "OAT CRUNCH", "whole grain, 500 g")
box(0.95, 1.2, 0.4, 1.7, (0.25, 0.55, 0.85), "B", "RICE POP", "lightly sweet, 400 g", yaw=-0.18)
light("Key", "AREA", (3.0, -3.5, 4.0), 400, target=(0, 0, 1.0), size=2.5)
light("Fill", "AREA", (-3.5, -2.0, 2.5), 150, target=(0, 0, 1.0), size=3.0)
camera((0.4, -6.0, 1.7), (0.0, 0.0, 1.0), lens=65)

Questions about this case

Can I make packaging mock-ups in Blender without textures?

Yes. Build the print from coloured geometry and extruded text objects, as this script does, or upload artwork as an asset.

How do I send textures with a .blend?

Send them as assets next to the file (the Python package does this automatically) or pack them into the .blend. Missing textures render pink.
